JAS座式緩衝德式三邊拉籃
建議載重: 40 kg
加入詢問車
產品說明
產品說明
- 座式緩衝滑軌
- 碳鋼亮鉻 / 不鏽鋼亮鉻 兩種材質選擇
產品介紹簡介
具緩衝回歸功能，回推輕聲不碰撞!
堅固耐用廚櫃必備拉籃~
示意圖
產品規格
碳鋼亮鉻
表格可左右移動瀏覽
| 型號 | 高X寬X深(mm) | 適用櫃體 | 組件 |
| KK160J1 0103KK3060JDOTL |
174x564x460 | 600 | KK3901A000x1 KK3502A0MCx1 |
| KK172J1 0103KK3072JDOTL |
174x684x460 | 720 | KK3901A000x1 KK3503A0MCx1 |
| KK180J1 0103KK3080JDOTL |
174x764x460 | 800 | KK3901A000x1 KK3501A0MCx1 |
| KK190J1 0103KK3090JDOTL |
174x864x460 | 900 | KK3901A000x1 KK3504A0MCx1 |
| KK110J1 0103KK3100JDOTL |
174x964x460 | 1000 | KK3901A000x1 KK3505A0MCx1 |
不鏽鋼亮鉻
表格可左右移動瀏覽
| 型號 | 高X寬X深(mm) | 適用櫃體 | 組件 |
| KK260J1 0103KK3060JDSTL |
174x564x460 | 600 | KK3901A000x1 KK3512A0MCx1 |
| KK272J1 0103KK3072JDSTL |
174x684x460 | 720 | KK3901A000x1 KK3513A0MCx1 |
| KK280J1 0103KK3080JDSTL |
174x764x460 | 800 | KK3901A000x1 KK3511A0MCx1 |
| KK290J1 0103KK3090JDSTL |
174x864x460 | 900 | KK3901A000x1 KK3514A0MCx1 |
| KK210J1 0103KK3100JDSTL |
174x964x460 | 1000 | KK3901A000x1 KK3515A0MCx1 |
組件
表格可左右移動瀏覽
| 三邊籃 | 碳鋼亮鉻 (不含滑軌/此為空籃本體實際尺寸) | ||
 |
型號 | 高x寬x深(mm) | 適用櫃體 |
| KK3502A0MC | 135x515x442 | 600 | |
| KK3503A0MC | 135x635x442 | 720 | |
| KK3501A0MC | 135x715x442 | 800 | |
| KK3504A0MC | 135x815x442 | 900 | |
| KK3505A0MC | 135x915x442 | 1000 | |
表格可左右移動瀏覽
| 三邊籃 | 不鏽鋼亮鉻 (不含滑軌/此為空籃本體實際尺寸) | ||
|
|
型號 | 高x寬x深(mm) | 適用櫃體 |
| KK3512A0MC | 135x515x442 | 600 | |
| KK3513A0MC | 135x635x442 | 720 | |
| KK3511A0MC | 135x715x442 | 800 | |
| KK3514A0MC | 135x815x442 | 900 | |
| KK3515A0MC | 135x915x442 | 1000 | |
表格可左右移動瀏覽
| 座式緩衝滑軌 | |||
 |
型號 | ||
| KK3901A000 | |||
